UHF digital radio microphone SOUNDSATION Wf-D140P TX Pocket E Bow
SOUNDSATION Presents UHF digital radio microphone SOUNDSATION Wf-D140P TX Pocket E Bow
The system SOUNDSATION Wf-D190 adopts a new digital transmission technology and hardware encryption of audio data that allow superior audio quality (compared to UHF analog systems), very low latency (better than 2.4 GHz systems) and maximum safety thanks to hardware encryption. The 16bit digital ID technology avoids interference even on the same frequency, and allows the continuous exchange of data between transmitter and receiver, such as the battery level, transmission power, Squelch operation, etc. The system is equipped with an automatic scanning and the frequency spectrum display, which allow the user to select the less disturbed frequencies in any environment in which it operates. It is equipped with 90 frequencies, divided into 10 groups, each of which contains 9 channels. User interface is very simple and intuitive, thanks to the TFT color display of the receiver and the simplicity of its setting menus. The hand transmitter and the body-Pack, on the other hand, are equipped with an LCD display with automatic shutdown function, to save the battery. The handheld microphone is also equipped with a rechargeable lithium battery that can be recharged via the USB port on the back of the receiver. Finally, there are two optional kits for rack mounting of 1 or 2 receivers, respectively, 1 or 2 standard from 19 rack units.
The system SOUNDSATION Wf-D190 adopts a new digital transmission technology and hardware encryption of audio data that allow superior audio quality (compared to UHF analog systems), very low latency (better than 2.4 GHz systems) and maximum safety thanks to hardware encryption. The 16bit digital ID technology avoids interference even on the same frequency, and allows the continuous exchange of data between transmitter and receiver, such as the battery level, transmission power, Squelch operation, etc. The system is equipped with an automatic scanning and the frequency spectrum display, which allow the user to select the less disturbed frequencies in any environment in which it operates. It is equipped with 90 frequencies, divided into 10 groups, each of which contains 9 channels. User interface is very simple and intuitive, thanks to the TFT color display of the receiver and the simplicity of its setting menus. The hand transmitter and the body-Pack, on the other hand, are equipped with an LCD display with automatic shutdown function, to save the battery. The handheld microphone is also equipped with a rechargeable lithium battery that can be recharged via the USB port on the back of the receiver. Finally, there are two optional kits for rack mounting of 1 or 2 receivers, respectively, 1 or 2 standard from 19 rack units.
- UHF Band 823-832mhz
- Digital audio transmission technology
- Digital Pilot 16 bit technology
- Signal level monitoring AF and the charge of the batteries directly on the receiver
- Double antenna with diversity technology
- No interference also on the same frequency
- Ultra reduced audio latency
- 48khz sampling frequency
- Frequency response 30-20hz
- Colorful TFT display and menu settings on the receiver
- Automatic frequency scan and spectrum display
- Ideal distance 50m (without obstacles)
- TX synchronization-RX with infrared for a quick system setting
- Professional headband microphone with professional cardioid dynamic capsule
- System frequency band: UHF 823-832mhz
- Bandwidth: 9mhz
- L922l
- Preset groups / channels: 10 groups, 9 frequencies in each group
- Dynamic interval: > 98db
- Total harmonic distortion: <0.1%
- Frequency response: 30Hz-20kHz / ± 2db
- Audio output level: 400mv balanced; 400mvdimensions System packaging (LXAXP): 436 x 104 x 324 mm
- Gross weight system packaging: 2.5 kg
- Power: DC 12V / 1000mA
- Power absorption of the receiver: 5W
- Receiver signal / noise ratio:> 98DB
- Receiver input sensitivity: -95dbm
- Transmission delay: <3MS
- Receiver size (LXAXP): 210 x 45 x 118 mm (antenna not included)
- Receiver antennas: 255 mm (not bent)
- Net weight of the receiver: 0.4 kg
