Radiomicrofono

SOUNDSATION Presents UHF radio microphone SOUNDSATION Wf-U11HA TX

Wf-U11 is the answer to all those who need a reliable and high quality sound and ease of use of a wireless microphone system. Ideal in teaching, for Portable Sound, for communication to the public and in contexts DJ, the WF system-U11 hits the brilliant and warm sound, thanks to the quality of the components and the capsule designed for all applications.

• UHF transmission with SMD technology
• 4 frequencies available in ISM band-Europe, free from licenses
• Simple user interface for Plug and Play configuration
• Ideal distance 30m (without obstacles)
• Handheld microphone with high quality dynamic cardioid capsule
• Frequency band: UHF 863-865mhz
• Bandwidth: 863.05 MHz, 864.15 MHz, 863.55 MHz, 865.00 MHz (Freq. WF-U11HA = 863.05 MHz)
• Dynamic interval: > 90DB
• Total harmonic distortion: <0.5%
• Frequency response: 40 18500 Hz / ± 3DB
• Packaging size: 436 x 104 x 324 mm
• Gross weight packaging: 2.0 kging: DC12V, 400mA
• Power absorption: <4W
• Signal / noise ratio:> 95DB
• Channel reception limit:> 80DB
• Receiver sensitivity: 10DBUV
• De-Emphasis: 75US
• Audio output level: 400mv balanced; 400mv unbalanced
• Dimensions (LXAXP): 211 x 43 x 115 mm (antenna not incl.)
• Antenna: 120 mm (not folded)
• Net weight: 0.295 kg
