Analog limiter compressor

Golden Age Project presents Comp 3a

Comp-3a a compressor / limiter from vintage soundproof. The path of the signal made with discrete components (resistance, capacitors, diodes, transistors) and separate transformers optimized for input and output stages. The use of discreet components allows you to reproduce the searched sonorities of the past - Most music, which cannot be obtained with current technologies. The COMP circuit-3a is inspired by the famous electro compressors-"Program Depending" optics of the past, in which the attenuation was controlled by an electrolyuminescent panel and a photoelectric cell. Compression control essentially based on Gain and Peak Reduction parameters allows you to get the desired sound easily. Comp-3a Includes a high-pass filter adjustable for better control via Sidechain, a link connector that allows you to connect two units for stereo operations with balance adjustment, and gain of the adjustable output stage. The limit switch varies the compression curve to use Comp-3rd as a limiter. The analog meter allows you to view both the output level and reducing the gain given by compression.

• Vintage compressor to a channel, with electro attenuator-Optical "Program Dependent" in T4-style
• Balanced entrance and exit via optimized transformers
• Quick compression control thanks to practices Gain and Peak Reduction knobs
• Sidechain with high adjustable pass
• Large Vu Meter, with the possibility of visualization of the attenuation or the output level.
• VU METER with reference level selectable between +4 and + 10dB. Adjustable zero with a special trim
• Bypass switch
• Double-size entrance and exit XLR and TRS
• Link connector (for using 2 Comp-3a for stereo operation) with activation button and balancing trim
• Adjustable input sensitivity
• Adjustable output stadium gain
• Mode Limiter
• Format: 2 unit racks in height, 1/ 2 unit rack in width
• Robust frame
• Weight: 3,1 Kg
