Features

• Four canals of sonally pure amplification in class D
• Inimitable and end digital DSP processor at 96 kHz
• SHARC algorithms for 4th generation DSP
• Power supply in Switch mode-mode
• 20,000 Watt RMS total output power (4 x 5,000 W RMS)
• Complete user interface manageable from the front panel
• Complete control software NOVA.Net on prot. Ethernet
• Analog audio inputs, AES3 and digital network (optional Dante card)
• Grouping and EQ functions multi-layer
• Powerful speakers and optimized presets
• LIR LINEAR STAGE CROSSOVER
• Peak and RMS multiple limiters
• Xover virtual limiter for passive systems
• PEQ & FIR equalizers on all entrances

Technical specifications

• Output channels: 4
• Total power: 20,000 Watt RMS
• E046e
• Digital signal processing: high-performance 96khz DSP on all entrances and outputs
• System control, monitoring and status alarms: Ethernet network, no volt relay and contact closure
• Energy saving mode: Standby After the time-defined time with Fast Wakeup function on the audio, user-deflayed ECOs definable and wakeup on command.
• Standby control and system wakeup: front panel switch, network control and audio detection
• Power Specification: Crest Factor of 4 (12db), 2-OHM NOMINAL LOAD: 5000 W / CREST FACTOR OF 2.8 (9DB), 4-OHM NOMINAL LOAD: 3000 W / CREST FACTOR OF 2 (6DB), 8-Ohm Nominal Load: 1500 W / Bridged, for Channel Pair, 4-Ohm Load: 10000 amplifier wtipo: class D
• Gain (DSP levels at 0dB): 32 dB
• Answer in French (4 ohm load): 7 Hz -30 kHz
• Total harmonic distortion (4 ohm load): <0.05% Typical, 1KHz Signal, AES17 Filter
• Damping Factor (REF 8 OHMS): 800 at the exit
• DSP: 40 bit, owner algorithm NOVA, 96 kHz sampling frequency, 10 snapshots, 50 presets for loudspeaker settings, Fir Filters
• Main Power Supply: NOVA High Performance Series Resonant
• INPUT MAIN: 85-240V 47HZ-63Hz with network voltage autodetect
• Protection Systems: In all circumstances the control and protection of the systems is set to provide maximum performance for a certain set of conditions, applying the limitations only under extreme circumstances. The muting can only intervene if a dangerous condition is detected by the control ristembling and normal operation is reproduced as soon as the danger condition stopped. An integrated notification system provides information on any problems found via OOPURE network to recrease the relay on the rear panel.
• Cooling: Double Various Fan-Speed, air circulation from the front to the back
