Multief for guitar TC ELECTRONIC NOVA System Guaranteed used, in excellent condition. Available for store test.

Inputs E Digital outputs

• Connectors: Phono RCA (S / PDIF)
• Formats: s / pdif (24 bit), eiaj cp-340, IEC 958
• Sample Rate: 44.1 KHZ, 48 kHz
  Analog inputs
• Connectors, balanced: ¼ "jack
• Impedance - Balanced / unbalanced LINE: 21/13 KOHM
• Line input level @ 0 DBFS: from 24 DBU to 0 DBU
• Line sensitivity @ 12 dB Headroom: from 12 DBU a -12 DBU
• Drive input level @ 0 DBFS: from 18 DBU a -6 DBU
• Drive sensitivity @ 12 dB Headroom: from 6 DBU a -18 DBU
• THD: < -100 dB (0.001%) @ 1 kHz
• Crosstalk: <-85 dB, from 20 Hz to 20 kHz
• Conversion to: 24 Bit, 128 x 'Oversampling bitstream'
  Analog outputs
• Conversion from: 24 bit, 128 x 'Oversampling Bitstream'
• Delay from: 0.63 / 0.68 ms @ S.R.= 48/44.1 kHz
• Connectors, balanced: ¼ "jack
• Output impedance: 40 ohm
• Max. Output level (balanced / unbalanced): 20 DBU / 14 DBU, R-Load = 1200 ohm
• Range of output: 20 DBU / 14 DBU / 8 DBU / 2 DBU
• Dynamic range:> 104 dB, from 20 Hz to 20 kHz
• THD: <-98 dB (0.0013%) @ 1 kHz
• Frequency response: + 0 /-0.3 dB, from 20 Hz to 20 kHz
  Control interface
• MIDI: IN / OUT / THRU: 5-pin DIN
• Pedal: Jack from 1/ 4 "
  General
• Display: LCD 24 x 2 characters
• Dimensions: 284 x 89 x 267 mm (11.2 "x 3.5" x 10.25 ")
• Weight: 1.85 kg (4.1 lb.)
• Power supply not included
• Energy consumption: <15 W

N.B. The photos are real and correspond to the product for sale.
