Digital plane 73 keys

NORD presents Floor 6

With north floor 6-73 The renowned Swedish Brand evolves the line of digital pianos from stage. The tool adopts a weighed keyboard 73 Third Three-type sensor keys from the precise touch and the cured dynamic detection. The sound generator offers two sections: Piano and Sample / Synth, with 4 simultaneous layer / split stamps and levels adjustment through 4 dedicated 4 faders, monitored by special LED strips. Up to 6 independent effects of great efficacy can also be applied on each section. North floor 6-73 It is finally compatible with free apps: North Plan / Sample Library, Sound Manager, Sound Editor to adapt it to personal artistic needs.

• Weighed keyboard 73 Premium keys Triple Sensor
• Two sound sections plan - Sample / Synth with Advanced Layering
• Adjustable section volume with faders equipped with LED strip
• Triple pedal 2 supplied

Plan and Sample Synths can use two independent layers, each of these can be used simultaneously in a split and layer mode, processed by the versatile effects and stored for their immediate recall

• 2 independent layers
• Filters: Soft, Mid, Bright, Dyno
• Dynamic Compression
• Unison function
• 3 Dynamic response curves
• Advanced Strigs Resonance

Thanks to the two layers available, on this section it is now possible to overlap for example a vertical and an electric plane, or divide the keyboard by playing with two different acoustic planes, or all other possible combinations. The wealth of physical controls on the panel makes every immediate and intuitive operation, the volume of each layer is adjustable through 2 dedicated faders, while as many STRI LEDs display their level; Dedicated keys allow you to change the dynamic response of the keyboard, the dynamic compressor, the filters plane, and the selection of sounds. This section also simulates the Advanced String Resonance the complex sympathetic resonance interaction between the strings of the noise plan, which occurs by pressing the Damper pedal and raising all the dampers.

• 2 independent layers
• Unison function
• Thru Vibrato
• Round Robin for the natural execution of repetitions
• Mono / Legato Glide (bearing)
• Envelope A D / S R with dynamic control

The same user interface and operating logic also regulates this section, we find the two faders and LED strips for the control and display of the levels, the activation keys for each layer, the envelope A D / S R, the selection of the samples, all commands a Hand reach for immediate interventions. This section can also be configured according to personal needs with the North Sound Manager, and you can also import personal samples using the free North Sample Editor software (Win / Mac).

• Independent FX for each layer
• Modulation effects with installments of installments and Amount
• Global reverb with adjustment for each layer, with pre-Delay, Choral and Bright / Dark Ways
• New Spring Reverb (spring reverb)
• New spin effect
• Delay with a new type of filter and flam and table tennis options
• Dedicated compressor
• Amp (amplifier and cabinet simulation) with new timbre variations.

E'able to generate up to 6 contemporary independent effects on the 4 layer of the instrument, a real-time real-time calculation capacity. We find two modulation stages mod 1/ 2 speeds (rate) and adjustable width (astonount), amp the physical modeling simulation of amplifiers, an effective one knob compressor, equalizer 3 bands with selectable medium frequencies, delay with time tap, ping / Pong and the new fashion Flam, and finally reverb with 6 algorithms including a new Spring Reverb (spring reverb) with Dry / Wet adjustment for each layer. In the central area of the instrument the general control zone is located in which the backlit OLED display of great visibility, with the transpose control buttons, the keyboard split and sound selection controls stands out

• Dual Piano and Dual Synth Layers
• OLED DISPLAY
• Seamless Transitions
• Split Point Crossfades
• 16 banks with 36 program - 576 Memory locations
• Organize mode for programs
• Live Mode - 6 with Program
• Global Transpose: + /- 6 semitones
• Global fine-tune: + /- 50 cents
• Transpose Program: + /- 6 semitones
• Keyboards 88 or 73-triple Sensor and Grand Weighted Action Notes
• Selectable split point with LED indicators (9 positions)
• North Triple Pedal 2 supplied
• MIDI on USB port
• 2 Independent Layers
• 2 GB of memory for plan sounds
• Internal sound database configurable with the North Sound Manager (Mac / Win)
• Polyphony 120 voices
• Categories: Grand, Upright, Electric, Digital / Layer, CLAV / Harpsichord and Misc
• 3 Dynamic response curves - Selectable Keyboard Touch (Heavy, Medium, Light)
• Stamp controls with custom settings for electric plans and clavinet
• String Resonance (Rope Resonance) for Grand Piano Piano Grand Piano and Uprughts
• Pedal Noise using the acoustic and electric planes with pedals: North Triple Pedal 1, North Triple Pedal 2 or North Single Pedal 2
• Dynamic Compression
• Unison function
• 2 Independent Layers
• 1 GB of memory for the North Sample Library
• Amplitude envelopes (amp envelope) with: Attack, Decay / Sustain and Release
• Vibrato with Rate / Amount Controls, Delay, Button or Pedal
• Unison with 3 levels
• Mono, tied and glide (bearing)
• Octave Transpose: -1/ +1 (-6 / + 6 in split mode, based on the position of the split)
• MoD 1: Tremolo, Pan 1 (Soft), Pan 2 (Hard), Spin, Wah, Ring Modulator (controllable via optional pedal)
• Mod 2: Phaser 1, Phaser 2, Flanger, Chorus 1, Chorus 2, Vibe, spin. Stereo / mono option for each effect
• Equalizer: For layer or global, 3-bands with medium sweepable frequencies (200 Hz - 8 kHz)
• Amp Twin, JC and Small, each with option: Alternate Tone
• One Knob compressor: For layer or global, compression control
• Delay: For layer or global
• Controls: Time, feedback and mix (dry / wet), table tennis with 3 amplitudes, tap-Time, Feedback Filter (HP /LP/ BP), FLAM
• Reverb: Global reverb with dosable Dry / Wet control for each layer.
• Types: Spring, Booth, Room, Stage, Hall and Cathedral Reverb, each with pre-Optional Delay
• Ways: Choral and Bright / Dark.
• Group Mode for effects
• 2 audio outputs (audio outputs) L & R - ¼ ", 6.35 mm Jacks, unbalanced
• 1 Input monitor input - 1/ 8 ", 3.5 mm stereo jack
• 1 Headphone output - ¼ ", 6.35 mm stereo jack
• 1 Input Sustain Pedal Input - ¼ ", 6.35 mm Jack. Compatible with North Triple Pedal or a momentary pedal
• Connector - 5 pin DIN for Triple Pedal Connector. Use the North Triple Pedal Pedal 2 supplied
• 1 Volume control pedal input (Pedal Input volume) - ¼ ", 6.35 mm TRS Stereo Jack.
• MIDI in, midi out - 5 pin din connectors
• USB - Type B for data transfer: sounds, Midi and OS upgrade
• IEC C14 power socket
• Size: 1069 mm (42 "), 121 mm (4.7"), 349 mm (13.7 ")
• Weight:16.2 kg (35.7 lbs)
• Accessories supplied: Dust cover, User manual, Power cable, North Triple Pedal 2
