The new qu-7D maintains the immediate and intuitive approach that has made the series famous, but it leads to a higher level. The audio benefits from up-to-date microphone preamplifiers and high-performance AD / to 96kHz converters, capable of preserving every minimum detail of the sound, guaranteeing a crystalline sound quality both input and output from the XCVI processor. The control of the mixer was revolutionized, while maintaining that simplicity that has been bridge between the analog and digital world for many technicians. Now you can work on four fully customizable layers, have more assignable softkeys to adapt the mixer to your needs and take advantage of an extremely flexible routing, which goes beyond the classic scheme 1:1 of the Qu series. Each channel has a dedicated display that indicates name, type or grip number, while a new color indicator allows you to quickly view the levels. The integrated touchscreen was also redesigned to offer faster and fluid navigation. Qu-7D is equipped with a 16 × 16 to 96khz or 48kHz dante interface, ideal for integration into complex systems or professional installations. The possibilities of recording and playback are numerous: a USB interface-C 32 × 32, multitrack support on SD card up to 32 channels, and stereo recording via USB port-A make the mixer versatile for any context. Thanks to the SLINK port, the qu can be connected to the Everything I / O range of Stagebox and Rack Allen & Heath, or directly to other brand consoles, allowing you to manage up to 128 × 128 audio channels at 96kHz. For the first time, the qu is compatible with Deep Processing, offering effects and processors derived from the dollive flagship system, appreciated on international tours and professional productions. The Gain Assistant and the Assistant feedback are also included, successfully introduced in the CQ series. The first automation and quickly optimizes channel gain, constantly monitoring the levels to avoid unwanted peaks, while the second analyze and automatically removes the feedback responsible frequencies, using up to 16 filters per output. Finally, the automatic 32-channel integrated mic mixer makes the qu-7D The perfect conference tool, talk shows and television broadcasts, without the need for external DSP or additional plugins, guaranteeing anything and an intelligent management of the microphones in real time. Qu-7D is much more than a simple update: it is the rebirth of a classic, with the power and flexibility required by the present.

• 96khz XCVI Core processor
• 6 Multi motors-FX with dedicated stereo returns
• Compatible with Deep Processing
• Mix architecture with 38 total inputs (32 mono / linkable, 3 stereo)
• 12 configurable mixes (6 Aux / Group Mono / Linkable, 6 Aux / Group stereo)
• 4 mono / linkable matrices for advanced routing
• Stereo LR main exit
• 32 Inputs Combo MIC / LINE XLR / JACK
• 2 Stereo Line Inputs (each with 2x TRS)
• 20 XLR line outputs
• 1 XLR socket dedicated to Talkback
• 2 line trs outputs
• 1 AES3 stereo digital output
• Smart Porta Slink 128 × 128 for Everything I / O expansion and system connections
• Dante interface 16 × 16 to 48/96 KHz with dedicated Ethercon (only qu-7d)
• Stereo headphone output with dedicated control
• Capacitive 7 "touchscreen for an intuitive control
• 33 fader motorized from 100 mm for a precise mix
• 4 Layer of Strip Canale completely customizable
• Remote control via free app for Windows, Macos, iOS and Android
• 8 assignable softkeys to optimize workflow
• Single / double Footswitch connection configurable
• USB port-A for recording and playback stereo and data transfer
• USB audio interface-C 32 × 32 for multi-channel recording and playback
• SD card slot for multitrack recording (16 × 16 @ 96 kHz, 32 × 32 @ 48 kHz)
• 12 V lamp socket
• Configurable chromatic metering LED on each channel
• Dimensions (LXPXA): 476x800x213
• Weight: 36 kg
