Mixer

SOUNDSATION presents Miomix 202m

Miomix 202M is a 4-channel mixer with an ideal USB reader for all small home recording applications, live executions and podcasting that require professional quality and maximum portability. The two MIC inputs are equipped with low noise preamplifier with the possibility of adapting to the main sound sources such as condenser microphones - thanks to the Phantom + 48V power supply, dynamic microphones, line and high impedance inputs (Guitars, bass, etc.). The line stereo input allows you to connect keyboards, CD players, DJ console, tablet, smart-Phones, etc. The USB and BT reader accepts files in WAV, MP3, WMA and FLAC format, and wireless audio streaming (BT). The digital eco effect with professional quality enriches your performance by allowing you to adjust speed and number of repetitions. An indispensable and reliable tool for all small audio applications.

• 4 channels in total
• 2 MIC / LINE channels with low noise PREAMP, Combo connector, HI input selection-Z For guitars, Phantom + 48V power supply, peak indicator
• 1 Line stereo channel with 6.3mm jack, pad + 4 / adapter-10DB and peak indicator
• USB reader / recorder in (WAV, MP3, WMA, FLAC and STREAMING Wireless Audio BT)
• EQ 2-Bands on the canals 1 and 2
• Eco digital effect with repetition adjustment, delay and level
• USB reader level control
• Headphone output with level control
• Main exits XLR with volume control
• Vu meter stereo with 2 6-led bars
• Light and robust structure for maximum flexibility and portability
• Input connections: XLR / Balanced Combo Jack (Channel 1), Jack from 6.3mm Balanced (channels 2-3), RCA stereo, mini-3mm stereo jack (channels 4-5)
• Output connections:Balanced XLR (Main L outputs-R), stereo jack from 6.3mm (Phones)
• Channel functions 1-2: PHANTOM + 48V power supply, Impedance selector (Line / Hi-Z), EQ 2-Bands (80Hz / 12khz + /-15db), Level Send effect, PAN position, Channel volume, LED peak indicator
• Channel functions 3-4: Impedance selector (+ 4 /-10DB), EQ 2-Bands (80Hz / 12khz + /-15db), Level Send effect, PAN position, Channel volume, LED peak indicator
• USB reader keys: Up / Rewind, Down / Forward, Play / Pause / Enter, Menu
• USB reader features: Streaming BT, Music Player, Audio Recorder, EQ curve selection
• USB Drive Format: FAT32 format - max 64 gbyte
• Reader file formats: WAV, MP3, WMA, FLAC and Streaming Wireless Audio BT
• Recorder file format: MP3 (48KHz / 16bit @ 128Kbps)
• Effect functions: ECO repetition number adjustment, ECO delay time adjustment, ECO level adjustment
• Vu Meter: 2x6 LED level indicator
• Maximum output level: 3 VRMS
• Frequency response: + /-0.5dB, 20Hz-20khz
• Dynamic interval: 102db
• THD + n @ 1khz: = 0.003%
• Crosstalk stereo: 92db
• Power: DC 5V, 0.5A
• Consumption: Max. 2.5W
• Dimensions (LXPXA): 166 x 165 x 66 mm
• Packaging dimensions (LXPXA): 300 x 208 x 87 mm
• Net weight: 0.9kg
• Gross weight: 1.2kg
