IMA-202 The version for wall installation of the popular IMA rack amplifier-200 and was designed for space-deficient places like small shops, bars, pizzerias. Integrates an MP3 media player and a FM radio tuner. E'Equipped with a microphone entrance. In addition to the MAIN audio output, the unit can be configured to use the internal amplifier as a stereo and an external amplifier for the zone signal or can be configured to take advantage of the internal amplifier as the only amplifier for the Main audio output and the zone output (in Dual Mono mode). E'Equipped with a Music On Hold output so you can connect the unit to a telephone system and suspend the spread when a call arrives. Includes possibilities of integration with another alarm system eventually present on the spot.

Features

• Mixer section for separate music and microphone
• Possibility to select the music source between Media Player with MP3 player, FM Tuner radio, 3 inputs for line sources each with Gain control and 1 3.5 mm stereo jack input for line audio source
• Media Player / Tuner RDS FM Radio integrated with USB Key and SD card input up to 16 GB; Visualization file name on the display, random and repeat playback.
• Microphone input with Phantom Power
• Adjustable Automatic Talkover (activated using the microphone)
• Master section with volume controls and equalizer 2 bands
• Master volume level also adjust from the rear side
• Zone section with independent volume control Assignable to the Master Zone or up to 2 rear panel line input
• 80W @ 4ohms integrated linear amplifier
• Splitable amplifier in 2 mono 50W @ 8ohm blocks each / 80W @ 4 ohm
• Silent cooling
• Overheating protection
• Linear power supply with roundabout transformer
• Two-block amplifier assignable to the master stereo channel or a mono area and master area mono

Technical specifications

• THD: <0.05%
• Damping Factor:> 300
• L382l
• Weight: 4.9 kg
