Rpm-6000 is a versatile combination of a 6in 2Out mixer and a 2in 6OUT splitter equipped with useful levels of level adjustment and impedance acting as a level switch between -10 DBV and +4 DBU or vice versa.Offre 6 identical input / output sections with level control, Panpot / Balance Control and an 8-stage LED indicator. Each section can be configured by means of a special switch to operate both as a mixer input channel and as an output of a split channel of a master input. If used as a mixer, the Main Input section can be used as 2 additional inputs bringing so to 8 channels available in Mixer mode. The versatility of this device ranges from submixing applications of keyboards on a stage audio system to use as a signal splitter in commercial audio systems. Rpm-6000 is a real problem solver for audio, resent and installers professionals.

Features

• 6 mono input / utout sections with level control, pan and balance. 8-stage LED level indicator and MIX / Plit switch
• LXR INPUT / OUTPUT balanced connectors for sections 1-2-3-4
• TRS INPUT / OUTPUT connectors for sections 5 and 6
• Each section works as a mixer or splitter in a totally independent way
• In Mixer mode the inputs also work as signal level converters between 10DBV and +4 DBU
• 1 Balanced XLR stereo input with level control and 4-stage LED indicator
• 1 Balanced XLR stereo output with level control and 4-stage LED indicator
• All switches with LED status indicator
• A wide voltage linear power supply for an excellent audio dynamic
• Metal houses with removable rack mounting fins

Technical specifications

• Signal / noise ratio:> 95dBu (unweighted 22Hz-22khz)
• Crosstalk Damping:> 65db
• E056e
• Answer to French: 20Hz 20 kHz
• Power supply: AC 215 / 230V ~ 50Hz-60Hz (20W)
• Dimensions: 483.0 × 44.5 × 162.0 mm LXAXP
• Weight: 2.36 kg
